Getx

https://pub.flutter-io.cn/packages/get

vscode 插件

Android Studio/Intellij 插件

本节目标

  • GetPage 对象
  • 路由层级控制
  • 路由中间件、鉴权
  • 404 处理
  • 路由跳转、替换、清除
  • 路由传值、返回值
  • 路由转场动画

开发环境

  • Flutter 2.1.0-12.1.pre
  • Dart 2.13.0
  • get: ^3.26.0

参考

视频

https://www.bilibili.com/video/BV1yU4y1876r/

代码

https://github.com/ducafecat/getx_quick_start

正文

初始 getx 项目

  • pubspec.yaml
1
2
3
dependencies:
  ...
  get: ^3.26.0
  • lib/pages/home/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
import 'package:flutter/material.dart';
import 'package:get/get.dart';

class HomeView extends StatelessWidget {
  const HomeView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("首页"),
      ),
      body: ListView(
        children: [
          // 路由&导航
          Divider(),

        ],
      ),
    );
  }
}
  • lib/common/routes/app_routes.dart
1
2
3
4
5
part of 'app_pages.dart';

abstract class AppRoutes {
  static const Home = '/home';
}
  • lib/common/routes/app_pages.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
import 'package:get/get.dart';

part 'app_routes.dart';

class AppPages {
  static const INITIAL = AppRoutes.Home;

  static final routes = [
    GetPage(
      name: AppRoutes.Home,
      page: () => HomeView(),
    ),
  ];
}
  • lib/main.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Future<void> main() async {
  runApp(MyApp());
}

class MyApp extends StatelessWidget {
  const MyApp({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return GetMaterialApp(
      debugShowCheckedModeBanner: false,
      initialRoute: AppPages.INITIAL,
      getPages: AppPages.routes,
    );
  }
}

编写 GetPage 定义

  • lib/pages/list/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
class ListView extends StatelessWidget {
  const ListView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("列表页"),
      ),
    );
  }
}
  • lib/pages/list_detail/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
class DetailView extends StatelessWidget {
  const DetailView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("详情页"),
      ),
      body: ListView(
        children: [
          ListTile(
            title: Text("导航-返回"),
            subtitle: Text('Get.back()'),
            onTap: () => Get.back(),
          ),
        ],
      ),
    );
  }
}
  • lib/common/routes/app_routes.dart
1
2
3
4
abstract class AppRoutes {
  static const Home = '/home';
  static const List = '/list';
  static const Detail = '/detail';
  • lib/common/routes/app_pages.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
GetPage(
  name: AppRoutes.Home,
  page: () => HomeView(),
  children: [
    GetPage(
      name: AppRoutes.List,
      page: () => ListView(),
      children: [
        GetPage(
          name: AppRoutes.Detail,
          page: () => DetailView(),
        ),
      ],
    ),
  ],
),

导航操作 命名、视图对象

  • lib/pages/home/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
ListTile(
  title: Text("导航-命名路由 home > list"),
  subtitle: Text('Get.toNamed("/home/list")'),
  onTap: () => Get.toNamed("/home/list"),
),
ListTile(
  title: Text("导航-命名路由 home > list > detail"),
  subtitle: Text('Get.toNamed("/home/list/detail")'),
  onTap: () => Get.toNamed("/home/list/detail"),
),
ListTile(
  title: Text("导航-类对象"),
  subtitle: Text("Get.to(DetailView())"),
  onTap: () => Get.to(DetailView()),
),

导航-清除上一个

  • lib/pages/home/index.dart
1
2
3
4
5
ListTile(
  title: Text("导航-清除上一个"),
  subtitle: Text("Get.off(DetailView())"),
  onTap: () => Get.off(DetailView()),
),

导航-清除所有

  • lib/pages/home/index.dart
1
2
3
4
5
ListTile(
  title: Text("导航-清除所有"),
  subtitle: Text("Get.offAll(DetailView())"),
  onTap: () => Get.offAll(DetailView()),
),

导航-arguments 传值+返回值

  • lib/pages/home/index.dart
1
2
3
4
5
6
7
8
9
10
ListTile(
  title: Text("导航-arguments传值+返回值"),
  subtitle: Text(
      'Get.toNamed("/home/list/detail", arguments: {"id": 999})'),
  onTap: () async {
    var result = await Get.toNamed("/home/list/detail",
        arguments: {"id": 999});
    Get.snackbar("返回值", "success -> " + result["success"].toString());
  },
),
  • lib/pages/list_detail/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
_buildBackListTileRow(Map? val) {
  return val == null
      ? Container()
      : ListTile(
          title: Text("传值 id = " + val["id"].toString()),
          subtitle: Text('Get.back(result: {"success": true}'),
          onTap: () => Get.back(result: {"success": true}),
        );
}

@override
Widget build(BuildContext context) {
  final details = Get.arguments as Map;
  final parameters = Get.parameters;

  return Scaffold(
    appBar: AppBar(
      title: Text("详情页"),
    ),
    body: ListView(
      children: [
        ListTile(
          title: Text("导航-返回"),
          subtitle: Text('Get.back()'),
          onTap: () => Get.back(),
        ),
        _buildBackListTileRow(details),
        _buildBackListTileRow(parameters),
      ],
    ),
  );
}

导航-parameters 传值+返回值

  • lib/pages/home/index.dart
1
2
3
4
5
6
7
8
ListTile(
  title: Text("导航-parameters传值+返回值"),
  subtitle: Text('Get.toNamed("/home/list/detail?id=666")'),
  onTap: () async {
    var result = await Get.toNamed("/home/list/detail?id=666");
    Get.snackbar("返回值", "success -> " + result["success"].toString());
  },
),
  • lib/pages/list_detail/index.dart
1
2
3
@override
Widget build(BuildContext context) {
  final parameters = Get.parameters;

导航-参数传值+返回值

  • lib/common/routes/app_routes.dart
1
static const Detail_ID = '/detail/:id';
  • lib/common/routes/app_pages.dart
1
2
3
4
5
...
GetPage(
  name: AppRoutes.Detail_ID,
  page: () => DetailView(),
),
  • lib/pages/home/index.dart
1
2
3
4
5
6
7
8
ListTile(
  title: Text("导航-参数传值+返回值"),
  subtitle: Text('Get.toNamed("/home/list/detail/777")'),
  onTap: () async {
    var result = await Get.toNamed("/home/list/detail/777");
    Get.snackbar("返回值", "success -> " + result["success"].toString());
  },
),

导航-not found

  • lib/pages/notfound/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
class NotfoundView extends StatelessWidget {
  const NotfoundView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("路由没有找到"),
      ),
      body: ListTile(
        title: Text("返回首页"),
        subtitle: Text('Get.offAllNamed(AppRoutes.Home)'),
        onTap: () => Get.offAllNamed(AppRoutes.Home),
      ),
    );
  }
}
  • lib/common/routes/app_routes.dart
1
static const NotFound = '/notfound';
  • lib/common/routes/app_pages.dart
1
2
3
4
static final unknownRoute = GetPage(
  name: AppRoutes.NotFound,
  page: () => NotfoundView(),
);
  • lib/main.dart
1
2
3
4
5
6
7
@override
Widget build(BuildContext context) {
  return GetMaterialApp(
    ...
    unknownRoute: AppPages.unknownRoute,
  );
}

导航-中间件-认证 Auth

  • lib/pages/login/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
class LoginView extends StatelessWidget {
  const LoginView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("登录"),
      ),
      body: ListTile(
        title: Text("返回首页"),
        subtitle: Text('Get.offAllNamed(AppRoutes.Home)'),
        onTap: () => Get.offAllNamed(AppRoutes.Home),
      ),
    );
  }
}
  • lib/pages/my/index.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
class MyView extends StatelessWidget {
  const MyView({Key? key}) : super(key: key);

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("我的"),
      ),
      body: ListTile(
        title: Text("返回首页"),
        subtitle: Text('Get.offAllNamed(AppRoutes.Home)'),
        onTap: () => Get.offAllNamed(AppRoutes.Home),
      ),
    );
  }
}
  • lib/common/routes/app_routes.dart
1
2
static const Login = '/login';
static const My = '/my';
  • lib/common/middleware/router_auth.dart
1
2
3
4
5
6
7
8
9
10
11
12
class RouteAuthMiddleware extends GetMiddleware {
  @override
  int priority = 0;

  RouteAuthMiddleware({required this.priority});

  @override
  RouteSettings? redirect(String route) {
    Future.delayed(Duration(seconds: 1), () => Get.snackbar("提示", "请先登录APP"));
    return RouteSettings(name: AppRoutes.Login);
  }
}
  • lib/common/routes/app_pages.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
// 白名单
GetPage(
  name: AppRoutes.Login,
  page: () => LoginView(),
),

GetPage(
  name: AppRoutes.My,
  page: () => MyView(),
  middlewares: [
    RouteAuthMiddleware(priority: 1),
  ],
),
  • lib/pages/home/index.dart
1
2
3
4
5
ListTile(
  title: Text("导航-中间件-认证Auth"),
  subtitle: Text('Get.toNamed(AppRoutes.My)'),
  onTap: () => Get.toNamed(AppRoutes.My),
),

Transition 转场动画

  • lib/common/routes/app_pages.dart
1
2
3
4
5
GetPage(
  name: AppRoutes.Detail_ID,
  page: () => DetailView(),
  transition: Transition.downToUp,
),
